Speedy 60KW-240KW DC EV Charger Station

1. Product name: DC EV Charging Station
2. Application:Electric Car Charging
3. Output Current:160A(230A/320A/360A/480A optional)
4. Charging Mode:Dc Fast
5. Warranty:1 years
6. Lead time:10-30 days
7. Color:White, gray, Customized Color
Boasting our own manufacturing facility along with a seasoned team spanning design, pre-sales, and after-sales services, we're fully equipped to offer tailor-made solutions based on clients' specific needs. This includes personalized touches like custom logos, color adjustments, and size modifications, among other possibilities.
  • Speedy charging station

  • hmhipech

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button


Speedy 60KW-240KW DC EV Charger Station

Superior quality meets striking aesthetics: Drawing on the distinctive design language of the Zhenxuan series, the product features a sleek, modern look with meticulous craftsmanship, achieving a perfect harmony between quality and visual appeal.

Safety and dependability guaranteed: It comes with multiple protective mechanisms, including short-circuit prevention, overheat protection, and emergency shutdown, ensuring all-round safety. The dual-layer casing—crafted from high-grade galvanized steel with anti-rust coating—adds durability. Boasting an IP54 rating, it handles harsh outdoor conditions effortlessly. Its optimized structural layout and unique air duct design further minimize failure rates.

Product Video
Fast Charger

Energy efficiency and cost savings: The product offers a broad output voltage range, delivers high operational efficiency, and keeps standby power usage low—all contributing to reduced running expenses.
Speedy 60KW-240KW DC EV Charger Station Station

Smart interaction capabilities: Equipped with a 7-inch color touchscreen, it ensures user-friendly operation and smart human-machine communication. It supports diverse connectivity options like Ethernet and 4G, along with multiple activation methods—including QR code scanning, card swiping, POS, and VIN. Additionally, it offers various charging modes such as automatic full charge and battery-level-based charging.
Pulg And Charger
This DC electric vehicle charging station supports both CCS2 and GBT DC standards, providing a wider range of flexible charging choices.
App Control
The system connects with the client's OCPP 1.6 application, allowing mobile apps to perform functions like initiating charging and processing payments.
Ocpp System
Supporting OCPP 1.6, the system facilitates human-computer interaction through two channels: a 7-inch touch screen and the user's dedicated OCPP application.


Application Scenario



About Us



ModelHM60DCD1、HM80DCE1、HM120DCF1、HM160DCG1、HM180DCH1、HM240DCI1
Prower380Vac+10%(L1+L2+L3+N+PE)
Current60~240A
ColorWhite , gray
Temperature-20~50℃/5%~95%
Protection level≥IP54
ProtectionOvervoltage, undervoltage, overcurrent, adhesion detection, insulation , lightning , emergency stop
EnvironmentNo pollution, such as salt, acid, smoke, etc
Storage temperature-40~80℃
Altitude<2000m
Cable length5m(Optional)
Size768mm*665mm*1800mm
Weight325KG
AuthenticationThird party type testing
