H6 Commercial Fuel Dispenser for Gas Stations

Overview of H6 Commercial Fuel Dispenser

The H6 commercial fuel dispenser represents a fueling solution designed for commercial fuel stations and enterprise fueling infrastructure. This model supports simultaneous dispensing of two fuel types through four independent nozzles, enabling parallel service for multiple vehicles. Manufactured by a facility with integrated sheet metal processing lines and component development capabilities, this equipment undergoes standardized quality inspection procedures before shipment. The dispenser accommodates gear pump, combined pump, or submersible pump configurations, matching different station layout requirements.

Core Configuration and System Architecture

This dispenser features four independent dispensing positions with 4.5-meter hoses, paired with automatic shut-off nozzles for each position. The electronic display system provides real-time volume and value readouts for each transaction. Constructed with galvanized steel housing and protective coating, the unit operates in outdoor environments across varying climate conditions. The system includes 8-layer electrical protection covering current leakage, over-temperature, voltage fluctuation, and lightning surge conditions.

Technical Specifications for H6 Fuel Dispenser

Flow Meter	Fuel Pump System	Automatic Nozzle

Operational Performance for Commercial Fueling

Metering Accuracy and Flow Control The aluminum alloy flowmeter delivers measurement accuracy within 0.3% with repeatability tolerance of 0.15%, supporting consistent transaction recording across daily operations. Standard pump flow rate reaches 55±5 L/min with maximum capacity at 80L/min, balancing dispensing speed with measurement stability. The system operates at inlet pressure of 54kpa or higher, maintaining outlet pressure within 0.3Mpa for consistent fuel delivery.

Safety Protection Systems The dispenser integrates emergency stop functionality, electrostatic discharge protection, and breakaway coupling mechanisms for hose separation events. Automatic nozzle shut-off prevents overflow conditions during fueling operations. Electrical systems include short circuit protection, over voltage protection, and voltage fluctuation compensation, supporting continuous operation within voltage supply variations. Noise output remains at or below 80dB during operation, complying with commercial area noise level requirements.

FAQ about H6 Fuel Dispenser

What pump configurations are compatible with the H6 model?

The H6 dispenser works with gear pump, combined pump, or submersible pump systems, allowing selection based on existing underground tank setup and station hydraulic requirements.

What voltage options does the H6 fuel dispenser support?

This model operates with either 220V or 380V power supply, accommodating different regional electrical grid standards for commercial procurement.

What is the metering accuracy of this equipment?

The flowmeter system maintains accuracy within 0.3% with 0.15% repeatability tolerance, providing consistent measurement for fuel transaction records.

What temperature range does this dispenser support?

The equipment functions within ambient temperatures from -25℃ to +55℃, suitable for deployment across different climate zones for industrial applications.
